One & Multiple-Piece Folder Gluer
AB-Piece, Irregular Boxes, Rapid Production.

The KS-1650M Folder Gluer offers high paper tolerance and fully replaces manual glue application.

Ideal for home appliances, large-scale outer packaging, and other corrugated products.

The KS-1650M is primarily engineered for large-format corrugated boxes. It delivers exceptional performance, especially for large-scale and high-strength corrugated containers that are traditionally difficult to produce manually.

Two-Piece RSC Carton

Two-Piece RSC Carton "A"： 450～1,650mm
Two-Piece RSC Carton "B" ：Min 400mm
Two-Piece RSC Carton "C"： 300～1,450mm
Two-Piece RSC Carton "D"：Min 150mm
Two-Piece RSC Carton "E" ：Min 20mm

Irregular Carton

Irregular Carton "A"：450～1,650mm
Irregular Carton "B"：Min 400mm
Irregular Carton "C"：300～1,450mm
Irregular Carton "D"：Min 150mm
Irregular Carton "E"：Max 150mm
Irregular Carton "F"：Min 20mm

One-Piece Carton

One-Piece Carton "A"：450～3,300mm
One-Piece Carton "B"：Min 400mm
One-Piece Carton "C"：300～1,450mm
One-Piece Carton "D"：Min 150mm
One-Piece Carton "E"：Min 20mm

Customized Carton

Customized Carton "A" ：450～1,650mm
Customized Carton "B" ：Min 400mm
Customized Carton "C" ：300～1,450mm
Customized Carton "D"：Min 190mm
Customized Carton "E" ：Min 20mm

Setup Time：Less than 15 minutes

Production width is adjusted via electronic control. Positioning baffles and pressure settings are designed for convenience, requiring minimal tools for component adjustments. This allows operators to become proficient quickly, ensuring a low learning curve.

Basic Configuration •Footprint：2.28M (L) x 1.25M (W)。
The KS-1650M offers a variety of optional equipment to enhance corrugated production, significantly boosting your overall efficiency.

Working Principle

Hot Melt & Cold Glue Injection SystemEquipped with independent Cold Glue and Hot Melt Auto. Glue Injection System for auto. glue application.

Production-mode choicesAccording to carton design and operator’s familiarity, choose the best way of production mode such as pedal, pressing button or auto. sensor detection. It improves the overall production effectively.

HMI Touching ScreenBy motor and screw drive for size and design adjustment, it takes 5-15 minutes only for changeover.

Automated selection of upgraded configurations

Pressing UnitAn effective solution for paper tension and bounce problem on paste side. It is suitable for producing high-strength or 5-ply corrugated cartons.
Dimension：2,005 x 2,000 x 1,050mm
Belt Size：1,670 x 3,820mm
Belt thickness：3mm
Horizontal Counter DeliveryPrecise calculation of carton volumes, operators can pack carton piles immediately. It is able to set quantity and distance for horizontal delivery freely.
Dimension：3,500 x 967 x 836mm
Belt Size：800 x 3,535mm
Belt thickness： 2mm
Electro-Hydraulic Lifting TablesIncrease the production efficiency. Automatically detect paper height, and then lift up to the proper position. It is suitable for making RSC and one-piece cartons.
Table size：900 x 600mm
Load bearing：300kg
Travel range：285-900mm

Seeing is Believing.

This video showcases the full range of box types and functionalities of this equipment. With its exceptionally versatile application, it is the ultimate tool for maximizing your business profitability.
